Located in Delhi, India, Vipul Sheets and Plates is a reputable producer and supplier of high-grade stainless steel 321 foils that are designed to provide exceptional performance in corrosive and high-temperature conditions. These foils, which are manufactured to satisfy international standards for accuracy and durability, are well-known for their exceptional formability, thermal stability, and resistance to corrosion. Vipul Sheets and Plates serves a number of industries, such as the automotive, chemical processing, aerospace, and heat treatment sectors. The business has established itself as a leading supplier of Stainless Steel 321 Foils in both domestic and foreign markets thanks to its emphasis on quality control, customised dimensions, and prompt delivery.
Chromium (17–19%), nickel (9–12%), titanium (at least five times the carbon content), carbon (up to 0.08%), and iron make up the base of stainless steel 321 foils. By preventing carbide precipitation, the titanium stabilisation improves resistance to intergranular corrosion. These foils have an approximate elongation of 40%, a yield strength of 205 MPa, and a tensile strength of 515 MPa. Since stainless steel 321 foils have outstanding oxidation resistance, thermal stability, and weldability, they can be used continuously at temperatures as high as 900°C without losing their mechanical integrity.
| Item | Stainless Steel 321 foil(Hot rolled, cold rolled) | |
| Thickness | 0.025 to 3 mm and as per Customer Requirement | |
| Width | 3 mm to 2000 mm and as per Customer Requirement | |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc | |
| Standard | JIS, AISI, ASTM, GB, DIN, EN, etc | |
| Surface | the surface and finish of stainless steel 321 foil: 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Grade | C | Mn | Si | P | S | Cr | N | Ni | Ti |
| SS 321 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 17.00 – 19.00 | 0.10 max | 9.00 – 12.00 | 5(C+N) – 0.70 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1457 °C (2650 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
DIN 1.4541 Foils offer several advantages, particularly in high-temperature applications. The addition of titanium ensures exceptional resistance to intergranular corrosion, making it ideal for welded structures exposed to heat. Its excellent oxidation and corrosion resistance allow it to perform reliably in harsh environments. Stainless Steel 321 also offers superior strength, durability, and resistance to scaling, making it suitable for a wide range of industrial applications. The material is highly versatile, with excellent formability and weldability, ensuring its adaptability for use in heat exchangers, reactors, furnaces, and chemical processing equipment.
| STANDARD | WERKSTOFF NR. | UNS | JIS | EN |
| SS 321 | 1.4541 | S32100 | SUS 321 | X6CrNiTi18-10 |
321 Stainless Steel Industries that need materials that are thin, strong, and heat-resistant frequently use foils. They are ideal for aerospace applications including thermal insulation, engine linings, and heat shields. In the automotive industry, these foils are used for exhaust systems and catalytic converter components. The chemical and petrochemical sectors use 321 foils in heat exchangers, furnace linings, and insulation wraps for piping systems exposed to corrosive media. They are also employed in electronics, pharmaceutical processing, and food-grade equipment due to their hygienic and corrosion-resistant properties. Their flexibility, strength, and heat resistance make them ideal for precision high-temperature applications.
