Vipul Sheets and Plates, a reputable manufacturer and supplier located in Delhi, India, specializes in high-quality ASTM A537 Sheets and Plates. These products are celebrated for their exceptional toughness, strength, and performance under pressure. Specifically crafted for pressure vessel applications, these plates are normalized to enhance their mechanical properties. Vipul Sheets and Plates is committed to delivering superior material quality, precise fabrication, and timely delivery, catering to the diverse needs of clients across various industries. Their ASTM A537 plates are a popular choice in the oil, gas, petrochemical, and power sectors, known for their reliability in high-pressure and high-stress environments.
ASTM A537 Sheets and Plates are made from carbon-manganese-silicon steel, offering impressive impact resistance and tensile strength. Typically, their composition includes a maximum of 0.24% carbon, 0.70–1.60% manganese, and 0.15–0.50% silicon. These plates undergo a heat treatment process called normalization, which enhances their strength and ductility. The mechanical properties boast a minimum yield strength of 290 MPa, tensile strength ranging from 485 to 620 MPa, and a minimum elongation of 20%. Renowned for their excellent weldability and notch toughness, A537 plates are well-suited for high-pressure service conditions and demanding structural applications.
| Condition | normalized |
| grade | ASTM A537 Cl 1 |
| sizes |
|
| Manufacturing method | Hot Rolled |
| certificates | EN 10204 3.1/2.2 |
| Brands | Thyssen, JSPL, Essar, JSW, POSCO, Clabecq, TATA, Dillinger, Uttam, SAIL |
| Uses |
|
| Surface | Painted, Natural |
| TPI | DNV, CE, TUV, KR, CCS, RINA, LR, GL, ABS |
| Mn | 0.70-1.60% |
| C | 0.24% |
| S Max. | 0.025% |
| Ph Max. | 0.025% |
| CU Max. | 0.35% |
| Si | 0.15-0.50% |
| CR Max. | 0.25% |
| NI Max. | 0.25% |
| MOLY Max. | 0.08% |
| Heat Treatment | Class | Thickness | Tensile Strength, minimum, ksi [MPa] | Yield Strength, minimum, ksi [MPa] |
|---|---|---|---|---|
| Q & T | Class 3 | 21/2 in. & under [65 milimeter and under] | 80 ksi [550] | 55 ksi [380] |
| Over 4 inch [Over 100 milimeter] | 70 ksi [485] | 40 ksi [275] | ||
| Over 21/2 to 4 inch [Over 65 to 100 milimeter] | 75 ksi [515] | 50 ksi [345] | ||
| Q & T | Class 2 | 21/2 inch and under [65 milimeter and under] | 80 ksi [550] | 60 ksi [415] |
| Over 4 inch [Over 100 milimeter] | 70 ksi [485] | 46 ksi [315] | ||
| Over 21/2 to 4 inch [Over 65 to 100 milimeter] | 75 ksi [515] | 55 ksi [380] | ||
| Normalized | Class 1 | 21/2 inch and under [65 milimeter and under] | 70 ksi [485] | 50 ksi [345] |
| Over 21/2 inch [Over 65 milimeter] | 65 ksi [450] | 45 ksi [310] |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Vipul Sheets and Plates based in Delhi, India, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
ASTM A537 sheets and plates offer several advantages, including excellent strength and durability, making them ideal for high-pressure and high-temperature applications like pressure vessels and boilers. They provide superior weldability, allowing for easy fabrication and joining. Their impact resistance ensures reliability even in harsh environments. Additionally, the heat-treated properties enhance their toughness, enabling them to withstand extreme conditions without compromising performance. With resistance to corrosion and excellent formability, ASTM A537 plates deliver long-lasting, reliable performance in demanding industrial settings, ensuring safety and efficiency.
Yes, we offer custom sizes for ASTM A537 Sheets and Plate to meet specific project needs. Our team at Vipul Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@vipulsheetsplates.com.
Primarily, ASTM A537 Sheets and Plates are utilized in the fabrication of pressure vessels, heat exchangers, and storage tanks within the oil, gas, petrochemical, and chemical processing industries. Their normalized structure guarantees outstanding mechanical performance in elevated pressure and moderate temperature environments. These plates also find applications in power generation plants, refineries, and boiler components, providing excellent resistance to stress and fatigue. Thanks to their toughness and weldability, A537 plates are perfect for projects that require durability, strength, and a long service life, even under fluctuating loads and temperature conditions.
