Vipul Sheets and Plates is a trusted manufacturer based in Delhi, India, specializing in premium stainless steel products. We offer a comprehensive range of stainless steel sheets and plates, including the highly sought-after 440C stainless steel. Renowned for its outstanding toughness, corrosion resistance, and strength, our 440C stainless steel sheets and plates are ideal for high-performance applications across industries such as aerospace, automotive, and construction. At Vipul Sheets and Plates, we are committed to delivering top-quality, reliable products that meet the highest industry standards.
Stainless Steel 440C Sheet and Plates is a high-carbon martensitic alloy known for exceptional toughness, strength and corrosion resistance. Its composition is about 1.0-1.2% carbon, 16-18% chromium, manganese, silicon, phosphorus and trace amounts of sulfur. The material provides corrosion resistance, making it ideal for products that require durability in extreme conditions. Mechanical properties include tensile strength of 860-1030 MPa, yield strength of 620 MPa, and heat-hardened strength of 58 to 60 HRC Stainless steel 440C is commonly used in bearings, valves and tools.
| Specifications | ASTM A240 / ASME SA240 |
|---|---|
| Width | 1000mm / 1219mm /1250mm / 1500mm / 2000mm |
| Length | 2000 mm / 2440 mm / 2500 mm / 3000 mm / 6000 mm |
| Thickness | 0.1mm to 12 mm Thk |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | Coils, Foils, Rolls, Plain Sheet, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
| 440C | min. max. | 0.95 1.20 | – 1 | – 1 | – 0.04 | – 0.030 | 16.00 18.00 | – 0.75 | – | – |
| Tempering Temperature (°C) | Tensile Strength (MPa) | Yield Strength 0.2% Proof (MPa) | Elongation (% in 50mm) | Hardness Rockwell (HR C) | Impact Charpy V (J) |
| Annealed* | 758 | 448 | 14 | 269HB max# | – |
| 204 | 2030 | 1900 | 4 | 59 | 9 |
| 260 | 1960 | 1830 | 4 | 57 | 9 |
| 316 | 1860 | 1740 | 4 | 56 | 9 |
| 371 | 1790 | 1660 | 4 | 56 | 9 |
| Grade | WERKSTOFF NR. | UNS |
| SS 440C | 1.4125 | S44004 |
| Grade | Density (kg/m3) | Elastic Modulus (GPa) | Mean Coefficient of Thermal Expansion (mm/m/°C) | Thermal Conductivity(W/m.K) | Specific Heat 0-100°C (J/kg.K) | Electrical Resistivity (nW.m) | |||
| 0-100°C | 0-200°C | 0-600°C | at 100°C | at 500°C | |||||
| 440 C | 7650 | 200 | 10.1 | 10.3 | 11.7 | 24.2 | – | 460 | 600 |
| Thickness | Plate Weight per Unit Area | Density |
|---|---|---|
| 3/16 inches | 0.06000 lbs/in²42.184176 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/4 inches | 0.08 lbs/in²56.245568 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/8 inches | 0.121 lbs/in²85.0714216 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/2 inches | 0.161 lbs/in²113.1942056 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 5/8 inches | 0.196 lbs/in²137.8016416 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/4 inches | 0.235 lbs/in²165.221356 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 7/8 inches | 0.274 lbs/in²192.6410704 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 inches | 0.313 lbs/in²220.0607848 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/4 inches | 0.391 lbs/in²274.9002136 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/2 inches | 0.47 lbs/in²330.442712 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 3/4 inches | 0.549 lbs/in²385.9852104 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 inches | 0.627 lbs/in²440.8246392 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/4 inches | 0.705 lbs/in²495.664068 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/2 inches | 0.784 lbs/in²551.2065664 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 3/4 inches | 0.862 lbs/in²606.0459952 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3 inches | 0.941 lbs/in²661.5884936 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless Steel 440C Sheets and Plates offer a wide range of advantages in both sheet and plate form. Known for their exceptional durability, they are ideal for applications requiring high resistance to wear and damage—such as nails, bearings, and valves. 440C stands out for its excellent corrosion resistance, particularly in water and chemically aggressive environments. This high-carbon stainless steel grade delivers impressive strength and thermal stability, retaining its mechanical properties even at elevated temperatures. In addition, 440C is well-suited for machining and fabrication, making it a preferred choice for precision manufacturing in demanding industries like automotive, aerospace, and medical equipment production.
Stainless Steel 440C Sheets and Plates are extensively used in applications that demand high strength, hardness, and corrosion resistance. Common uses include circular bearings, valve components, cutting tools, and surgical instruments. Thanks to its exceptional hardness, 440C is also well-suited for high-performance machinery, industrial knives, and precision dies. Its superior corrosion resistance makes it ideal for use in challenging environments across industries such as aerospace, automotive, and medical. With a perfect balance of accuracy, durability, and reliability, Stainless Steel 440C is the material of choice for precision-engineered applications.
