Vipul Sheets and Plates, a Delhi, India-based manufacturer and supplier of **Stainless Steel 410 Sheets and Plates**, provides long-lasting and high-strength products for different industrial and mechanical uses. Praised for their superior hardness, wear resistance, and medium corrosion resistance, these sheets and plates are best suited for uses requiring heat treatment and mechanical stress. Vipul Sheets and Plates produces all SS 410 products internationally, serving industries that include automotive, tool making, oil & gas, and thermal processing.
**SS 410 Sheets and Plates** are martensitic stainless steels containing 11.5–13.5% of chromium and approximately 0.15% carbon, which makes them capable of being hardened by heat treatment. They provide tensile strength of about 450–750 MPa, excellent toughness, and high scaling resistance up to 650°C. SS 410 is ferromagnetic in both annealed and hardened conditions and exhibits good corrosion resistance in mild atmospheres, water, and certain chemicals—making it ideal for wear-resistant and moderate corrosive environments.
| Standard | ASTM A240, ASME SA240 |
| Dimensions | ASTM, ASME, and API |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Thickness | 4mm-100mm |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Surface Finish | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, chequered, embossed, hairline, sand blast, Brush, etching, Hot rolled plate (HR), Cold rolled sheet (CR), SATIN (Met with Plastic Coated) etc |
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Grade | Cr | Mn | Si | Ni | C | P | S | Fe |
| SS 410 | 11.50 – 13.50 | 0.0 – 1.50 | 0.0 – 1.00 | 0.0 – 0.75 | 0.08 – 0.15 | 0.0 – 0.04 | 0.0 – 0.02 | Balance |
| Tensile Strength Ksi (Mpa) | 0.2% Offset Yield Strength Ksi (Mpa) | Elongation, % in 2″ (51 mm) | Hardening Response HRC | HRB |
| 65 (450) – 74 (510) | 30 (205) – 42 (290) | 20 – 34 | 38-45 | 82-96 |
| Grade | WERKSTOFF NR. | UNS | AISI | BS | SIS | EN | JIS | AFNOR |
| SS 410 | 1.4006 | S41000 | 410 | 410S21 | 2302 | X12Cr13 | 410 | Z10C13/Z13C13 |
| Grade | Density (kg/m3) | Elastic Modulus (GPa) | Mean Coefficient of Thermal Expansion (m/m/0C) | Thermal Conductivity (W/m.K) | Specific Heat 0-1000C (J/kg.K) | Electrical Resistivity (n.m) | |||
| 0-1000C | 0-3150C | 0-5380C | at 1000C | at 5000C | |||||
| 410 | 7750 | 200 | 9.9 | 11.4 | 11.6 | 24.9 | 28.7 | 460 | 570 |
| Material | Size | Thickness |
| PLATES & SHEETS | 1000 mm x 2000 mm | 0.1mm To 100 mm Thickness |
| 1220 mm x 2440 mm (4′ x 8′) | ||
| 1250 mm x 2500 mm | ||
| 1500 mm x 3000 mm | ||
| 2000 mm x 4000 mm | ||
| 2000 mm x 2000 mm |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless steel 410 sheets and plates offer a variety of benefits including excellent hardness and corrosion resistance, making them ideal for hard-wearing components such as cutlery, fasteners and valves especially in soft corrosive environments moderate corrosion resistance due to chromium content. Their high strength and durability enable them to be used in buildings and mechanical components. In addition, they can be heat treated, increasing the mechanical properties. Simple and affordable devices further enhance their appeal, making them a great choice for industries such as automotive, aerospace and construction.
**Stainless Steel 410 Sheets and Plates** find extensive application in industries that demand materials combining strength, heat resistance, and machinability. In engineering and automotive applications, they are utilized for engine parts, pump shafts, and fasteners. SS 410 is utilized by the tool-making industry for industrial blades, cutlery, and surgical instruments because of its hardness and edge retention. In the oil and gas industry, it is applied in valve components, pipeline components, and bolts. SS 410 is also used in furnace components, screens, and other structural uses subjected to mechanical stress and mild corrosive environments.
