A reputable manufacturer and supplier of premium stainless steel 316L sheets and plates, Vipul Sheets and Plates is based in Delhi, India. These plates are designed to provide exceptional corrosion resistance and durability in demanding environments. Vipul Sheets and Plates, a company that specialises in high-performance stainless steel products, provides precisely finished 316L sheets and plates that are perfect for the food processing, chemical, pharmaceutical, and marine industries. 316L stainless steel, which is well-known for having a low carbon content, provides enhanced weldability and sensitisation resistance. With a commitment to quality, customer satisfaction, and on-time delivery, Vipul Sheets and Plates serves both domestic and international markets with customized material solutions.
With iron as the base, stainless steel 316L sheets and plates have a low carbon content (maximum 0.03%), chromium (16–18%), nickel (10–14%), and molybdenum (2–3%). Excellent corrosion resistance is provided by this composition, especially in acidic and chloride-containing environments. The alloy has an elongation of 40% or more, a yield strength of about 170 MPa, and a tensile strength of about 485 MPa. At high temperatures, 316L retains its good mechanical strength and offers exceptional resistance to pitting and crevice corrosion. Because there is less chance of carbide precipitation during welding operations, its low carbon content improves weldability.
| Specifications | : | ASTM A240 / ASME SA240 |
| Thickness | : | 4mm-100mm |
| Width | : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length | : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Surface | : | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
| Finish | : | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | : | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 316L | 0.035 max | 2 max | 1.00 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 10.00 – 14.00 | 68.89 min |
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| SS 316L | 8.0 g/cm3 | 1399 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316L | 1.4404 / 1.4435 | S31603 | SUS 316L | 316S11 / 316S13 | 03Ch17N14M3 / 03Ch17N14M2 | Z3CND17‐11‐02 / Z3CND18‐14‐03 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 |
| Material | Size | Thickness |
| PLATES & SHEETS | 1000 mm x 2000 mm | 0.1mm To 100 mm Thickness |
| 1220 mm x 2440 mm (4′ x 8′) | ||
| 1250 mm x 2500 mm | ||
| 1500 mm x 3000 mm | ||
| 2000 mm x 4000 mm | ||
| 2000 mm x 2000 mm |
| Surface Finish | Definition | Application |
|---|---|---|
| 2B | Those finished, after cold rolling, by heat treatment, pickling or other equivalent treatment and lastly by cold rolling to given appropriate luster. | Medical equipment, Food industry, Construction material, Kitchen utensils. |
| BA | Those processed with bright heat treatment after cold rolling. | Kitchen utensils, Electric equipment, Building construction. |
| NO.3 | Those finished by polishing with No.100 to No.120 abrasives specified in JIS R6001. | Kitchen utensils, Building construction. |
| NO.4 | Those finished by polishing with No.150 to No.180 abrasives specified in JIS R6001. | Kitchen utensils, Building construction, Medical equipment. |
| HL | Those finished polishing so as to give continuous polishing streaks by using abrasive of suitable grain size. | Building Construction. |
| NO.1 | The surface finished by heat treatment and pickling or processes corresponding there to after hot rolling. | Chemical tank, pipe |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless steel 316L sheets and plates offer many advantages, including excellent corrosion resistance, especially against chloride and harsh environments, making them ideal for marine and chemical consumption use This low-carbon material reduces carbide precipitation, enhances weldability and prevents intergranular corrosion. 316L is highly resistant to high temperature pitting, crevice corrosion and oxidation. It also has excellent mechanical properties, such as high strength, durability and flexibility. These characteristics make it suitable for industries such as pharmaceuticals, food processing and petrochemicals, where reliability and long-term performance are important.
Industries that require high corrosion resistance, strength, and hygienic performance frequently use stainless steel 316L sheets and plates. They are utilised in the marine industry for structural elements exposed to seawater, desalination plants, and boat fittings. Because of its ease of sterilisation and resistance to harsh chemicals, 316L is used in the chemical and pharmaceutical industries for processing equipment, tanks, and piping. It is utilised in food processing for handling systems and kitchen appliances. It is also used in heat exchangers, medical devices, and architecture. The alloy is very adaptable due to its superior formability, weldability, and resistance to corrosive environments.
