Located in Delhi, India, Vipul Sheets and Plates is a top producer and supplier of high-quality stainless steel 310S sheets and plates, which are renowned for their exceptional resistance to corrosion and high temperature strength. These plates and sheets are perfect for demanding industrial applications because they are made especially to function in high-heat and oxidising environments. To satisfy the demands of industries like furnace engineering, petrochemicals, and heat treatment, Vipul Sheets and Plates guarantees accurate manufacturing, quality control, and prompt delivery. The company provides dependable solutions that are suited to both domestic and international markets, with a strong emphasis on quality and customer satisfaction.
Chromium (24–26%) and nickel (19–22%) make up stainless steel 310S Sheets and Plates, while the low carbon content (≤0.08%) improves weldability and lowers sensitisation. The base element is iron, with traces of silicon, sulphur, and manganese. Excellent resistance to oxidation at high temperatures is provided by this alloy. Its elongation is about 40%, its yield strength is about 205 MPa, and its tensile strength is about 515 MPa. The 310S grade is appropriate for prolonged exposure in high-heat applications because it has exceptional creep resistance and maintains mechanical strength at high temperatures.
| Specifications | ASTM A240 / ASME SA240 |
|---|---|
| Width | 1000mm / 1219mm /1250mm / 1500mm / 2000mm |
| Length | 2000 mm / 2440 mm / 2500 mm / 3000 mm / 6000 mm |
| Thickness | 0.1mm to 12 mm Thk |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | Coils, Foils, Rolls, Plain Sheet, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
|---|---|---|---|---|---|---|---|---|---|
| SS 310 | 0.015 max | 2.0 max | 0.15 max | 0.020 max | 0.015 max | 24.00 – 26.00 | 0.10 max | 19.00 – 21.00 | 54.7 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.9 g/cm3 | 1402 °C (2555 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 40 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 310S | 1.4845 | S31008 | SUS 310S | 310S16 | 20Ch23N18 | – | X8CrNi25-21 |
| Material | Size | Thickness |
| PLATES & SHEETS | 1000 mm x 2000 mm | 0.1mm To 100 mm Thickness |
| 1220 mm x 2440 mm (4′ x 8′) | ||
| 1250 mm x 2500 mm | ||
| 1500 mm x 3000 mm | ||
| 2000 mm x 4000 mm | ||
| 2000 mm x 2000 mm |
| 2000MM X 1000MM X 3MM | 2000MM X 1000MM X 6MM |
| 2500MM X 1250MM X 4MM | 2500MM X 1250MM X 8MM |
| 3000MM X 1500MM X 3MM | 3000MM X 1500MM X 6MM |
| 3000MM X 1500MM X 4MM | 3000MM X 1500MM X 8MM |
| 2000MM X 1000MM X 5MM | 2500MM X 1250MM X 10MM |
| 2500MM X 1250MM X 3MM | 2500MM X 1250MM X 6MM |
| 4000MM X 2000MM X 3MM | 4000MM X 2000MM X 6MM |
| 2500MM X 1250MM X 5MM | 3000MM X 1500MM X 10MM |
| 2000MM X 1000MM X 4MM | 2000MM X 1000MM X 8MM |
| 4000MM X 2000MM X 4MM | 2000MM X 2000MM X 10MM |
| 3000MM X 1500MM X 5MM |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless steel 310S sheets and plates offer high superior strength and excellent oxidation resistance, making them ideal for heat-intensive applications Their high corrosion resistance ensures durability in harsh, chemical environments including marine conditions. Due to its excellent weldability and formability, it is easily manufactured for various applications. The lower maintenance and longer service life of the products results in lower costs over time. The high chromium and nickel content increases thermal stability and creep resistance, making it suitable for furnaces, heat exchangers and other industrial equipment where severe thermal stresses occur.
In high-temperature settings where resistance to oxidation and scaling is crucial, stainless steel 310S sheets and plates are frequently utilised. Heat exchangers, furnace linings, combustion chambers, and kiln components in the metallurgical and heat treatment sectors are important uses. They are utilised in thermal process equipment, catalytic systems, and radiant tubes in the petrochemical and refinery industries. Because of its thermal stability, 310S is also used in flue gas systems, incinerators, and steam boilers. It is also perfect for use in food processing, cement plants, and chemical production under harsh heat and corrosive conditions because of its resistance to sulfidation and carburisation.
