**Vipul Sheets and Plates**, Delhi, India, is a leading manufacturer and supplier of **Stainless Steel 17-7 PH Sheets and Plates** with high-strength, corrosion-resistant, and heat-treatable stainless steel products designed for aerospace, chemical, and industrial uses. Renowned for possessing exceptional mechanical properties along with dimensional stability, SS 17-7 PH is a blend of both martensitic and austenitic stainless steels’ benefits. Vipul Sheets and Plates provides high-quality sheets and plates in compliance with tough international standards for precision and performance.
**Stainless Steel 17-7 PH Sheets and Plates** are precipitation-hardened stainless steel items made of about 17% chromium and 7% nickel with traces of aluminum so that age hardening can be facilitated. This alloy provides high tensile strength (to 1310 MPa), good fatigue and stress corrosion cracking resistance, and retains its mechanical properties up to 600°F (316°C). It is magnetic in solution-treated and heat-treated conditions and can be cold formed in the annealed condition and hardened by aging.
| Specifications : | ASTM A693 / ASME SA693 |
| Standard : | ASTM, ASME and API |
| Thickness : | 4.0mm – 100mm |
| Shims Thickness : | Range from .01″ to .0125″ |
| Specialize : | Shim Sheet, Perforated Sheet, B. Q. Profile. |
| Form : | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) |
| Finish : | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Grade : | SS 17-7 PH, (UNS S17700) |
| Grade | C | Mn | Ni | Al | Cr | P | Si | S | Fe | |
| 17-7 PH | min. | – | – | 6.50 | 0.75 | 16 | – | – | – | – |
| max. | 0.09 | 1.0 | 7.75 | 1.50 | 18 | 0.040 | 1.0 | 0.030 | Balance | |
| Properties | Metric | Imperial |
| Tensile strength | 1170 MPa | 170000 psi |
| Yield strength | 965 MPa | 140000 psi |
| Modulus of elasticity | 204 GPa | 29600 ksi |
| Poisson’s ratio | 0.27-0.30 | 0.27-0.30 |
| Elongation at break | 6% | 6% |
| Hardness, Rockwell C | 38 | 38 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
SS DIN 1.4568 Sheets and Plates offer numerous advantages, including exceptional strength, high fatigue resistance, and excellent stress-corrosion cracking resistance. This alloy maintains good mechanical properties at elevated temperatures, making it ideal for aerospace and industrial applications. It also provides excellent formability and can be easily hardened through heat treatment. The material exhibits superior weldability, ensuring reliable performance in critical environments. Its corrosion resistance, combined with high durability, makes it a preferred choice for manufacturing components that require both strength and resistance to harsh conditions.
| Properties | Metric | Imperial |
| Density | 7.80 g/cm3 | 0.282 lb/in3 |
Yes, we offer custom sizes for Stainless Steel 17-7 PH Sheet and Plates to meet specific project needs. Our team at Vipul Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@vipulsheetsplates.com.
| STANDARD | WERKSTOFF NR. | UNS | JIS | AFNOR | BS | GOST | EN |
| SS 17-7 PH | 1.4568 | S17700 | SUS 631 | Z8CNA17.07 | 301S81 | – | X7CrNiAl 17 7 |
| Material | Size | Thickness |
|---|---|---|
| PLATES / SHEETS | 1000 mm x 2000 mm | 0.1mm To 100 mm Thickness |
| 1220 mm x 2440 mm (4′ x 8′) | ||
| 1250 mm x 2500 mm | ||
| 1500 mm x 3000 mm | ||
| 2000 mm x 4000 mm | ||
| 2000 mm x 2000 mm |
**17-7 PH Sheets and Plates of Stainless Steel** find extensive applications in situations where high strength and moderate resistance to corrosion are needed. They are used in structural parts, springs, and fasteners in the aerospace sector. They are employed for tanks, valves, and high-pressure components in the chemical processing industry. They can be used in medical equipment, heat exchangers, nuclear reactor parts, and machinery in the industrial sector. They have the properties of strength, corrosion resistance, and low distortion upon heat treatment due to which they find applications in demanding, high-performance environments.
