Vipul Sheets and Plates is a well-known manufacturer and supplier of Stainless Steel 17-4 PH Sheets and Plates, located in Delhi, India. They’ve built a solid reputation for providing high-performance stainless steel products that meet the demands of industries needing robust, corrosion-resistant, and heat-treatable materials. Stainless Steel 17-4 PH is a type of precipitation hardening martensitic stainless steel, offering a remarkable blend of high strength, hardness, and decent corrosion resistance. Vipul’s SS 17-4 PH Sheets and Plates are crafted to adhere to strict quality standards and find extensive applications in sectors like aerospace, defense, petrochemical, and power generation.
These Stainless Steel 17-4 PH Sheets and Plates mainly consist of 15–17.5% chromium, 3–5% nickel, and 3–5% copper, along with trace amounts of niobium, manganese, silicon, and a carbon content of up to 0.07%. This alloy can undergo heat treatment to achieve impressive mechanical strength and hardness. The mechanical properties can vary based on the heat treatment process, with tensile strength reaching up to 1100 MPa and yield strength up to 1000 MPa, all while maintaining good toughness and corrosion resistance. The material retains excellent strength and mechanical properties in both annealed and aged states.
| Grade | Stainless Steel 17-4 PH | UNS S17400 |
| Standard | ASTM B625 / ASME SB625 |
| Thickness | 0.1mm To 100 mm |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Surface | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | Sheets, Plates, Coils, Slatting Coils, Perforated Coils |
| Applications | Off-Shore Oil Drilling Companies, Power Generation, Petrochemicals, Gas Processing, Specialty Chemicals, Pharmaceuticals, Pharmaceutical Equipment, Chemical Equipment, Sea Water Equipment, Heat Exchangers, Condensers, Pulp and Paper Industry |
| Cr | Mn | Si | Ni | P | S | C | Cu | cb+Ta | |
| MIN | 15 | – | – | 3 | – | – | – | 3 | 0.15 |
| Max | 17.5 | 1 | 1 | 5 | 0.04 | 0.03 | 0.07 | 3.5 | 0.45 |
| UTS (Tensile) Ksi (Mpa) | .02% Yield Strength Ksi (Mpa) | Elongation % in 2” (51mm) | Hardness Rockwell C |
| 160 | 145 | 5 | 35 |
| (1103) | (1000) |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless Steel 17-4 PH Sheets and Plates offer numerous advantages, including high strength, excellent corrosion resistance, and outstanding toughness, even in challenging environments. DIN 1.4542 Sheets and Plates are heat-treatable, allowing customization of mechanical properties to suit specific applications. These sheets exhibit superior resistance to stress corrosion cracking and pitting, making them ideal for marine and chemical environments. Their exceptional weldability and ease of fabrication simplify manufacturing processes. With excellent performance at moderate to high temperatures, they are widely used in aerospace, petrochemical, and food processing industries, ensuring reliability, durability, and long service life in demanding
| Surface finish | Thickness (mm) | Width (mm) |
|---|---|---|
| Stainless Steel 17-4 PH 1D – Hot rolled, heat treated, pickled Plate & Sheet | 2.4–12.7 | max. 2032 |
| 2R – Stainless Steel 17-4 PH Cold-rolled, bright-annealed Sheet & Plate | 0.05–1.50 | 3–649 |
| 2H – Stainless Steel 17-4 PH Work hardened Plate & Sheet | 0.05–1.50 | 3–630 |
| 2B – Stainless Steel 17-4 PH Cold rolled, heat treated, pickled, skin passed Sheet & Plate | 0.25–8.0 | max. 2032 |
| 2D – Stainless Steel 17-4 PH Cold rolled, heat treated, pickled Plate & Sheet | 0.4–6.35 | max. 1524 |
| 2E – Stainless Steel 17-4 PH Cold rolled, heat treated, mechanically descaled Sheet & Plate | 0.4–8.0 | max. 2032 |
| 2R – Stainless Steel 17-4 PH Cold rolled, bright annealed Plate & Sheet | 0.25–3.5 | max. 1524 |
| 2H – Stainless Steel 17-4 PH Work hardened Sheet & Plate | 0.4–6.35 | max. 1524 |
| Stainless Steel 17-4 PH Polished, brushed Plate & Sheet | 0.5–4.0 | max. 1524 |
| Deco | 0.3–3.5 | max. 1524 |
| Stainless Steel 17-4 PH Coil | 0.30–3.5 | max. 1,524 |
Yes, we offer custom sizes for Stainless Steel 17-4 PH Sheet and Plates to meet specific project needs. Our team at Vipul Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@vipulsheetsplates.com.
| STANDARD | WERKSTOFF NR. | UNS |
| SS 17-4 PH | 1.4542 | S17400 |
| Material | Size | Thickness |
|---|---|---|
| PLATES / SHEETS | 1000 mm x 2000 mm | 0.1mm To 100 mm Thickness |
| 1220 mm x 2440 mm (4′ x 8′) | ||
| 1250 mm x 2500 mm | ||
| 1500 mm x 3000 mm | ||
| 2000 mm x 4000 mm | ||
| 2000 mm x 2000 mm |
You’ll find Stainless Steel 17-4 PH Sheets and Plates in a variety of applications, including aerospace components, nuclear reactors, pressure vessels, turbine blades, and high-performance mechanical parts. Their unique combination of corrosion resistance and high mechanical strength makes them perfect for structural components that face tough environments. They’re also utilized in marine applications, chemical processing, and the oil and gas industries, particularly where high strength and dimensional stability are crucial. Thanks to their machinability, weldability, and heat treatability, these plates are a go-to choice for precision components and critical load-bearing structures.
