Vipul Sheets and Plates, Delhi, India, is a reliable Stainless Steel 15-5 PH Sheets and Plates manufacturer and supplier of high-performance stainless steel solutions for critical mechanical and structural applications. Produced according to international standards, these plates and sheets have vast applications in aerospace, petrochemical, marine, and power generation sectors. Renowned for their high strength, resistance to corrosion, and toughness, Vipul’s 15-5 PH stainless steel products come in different sizes and conditions and are supported by timely delivery and accessible customer service throughout India and international markets.
Stainless Steel 15-5 PH is a martensitic precipitation-hardening stainless steel alloy containing chromium (14–15.5%), nickel (3.5–5.5%), and controlled amounts of copper, manganese, and carbon. It has excellent mechanical strength, hardness, corrosion resistance, and stability of dimensions following heat treatment. 15-5 PH is rich in transverse toughness and higher uniformity than its predecessor, 17-4 PH, and is supplied in numerous heat-treated conditions (H900–H1150).
| SS 15-5PH Sheet Plate Grade | SS 15-5 PH / WNR 1.4545 / UNS S15500 |
| SS 15-5 PH Sheet Plate | ASTM A240 / ASME SA240 |
| Steel 15-5PH Sheet Plate Type | Sheet, Plates, Flat, Coils, Ring, Shim Sheet, Strips, Checkered Plate, Circle, Perforated Sheet, Profile, Blank. |
| SS 15-5 PH Sheet Plate Size Range | 1220mm x 2440mm, 1000 mm x 2000mm, 1500mm x 3000mm to 6000mm, 2000mm x 4000mm to 6000mm, 1250mm x 2500mm & Cut Pieces |
| UNS S15500 Steel 15-5PH Plate Finish | SATIN (Met with Plastic Coated), Hot Rolled Plate (HR), Cold Rolled Sheet (CR), 2B, 2D, BA NO(8) |
| Steel 15-5 PH Sheet Hardness | Hard, Spring Hard, Half Hard, Quarter Hard, Soft, etc. |
| SS 15-5 PH Sheet Plate Thickness | 0.1 MM TO 300 MM |
| SS 15-5PH Plate & Sheets Surface Finish | Brushed Finish, No.8 Finish, Brush, No.1 Finish, 2D Finish, 2B Finish, Hair Line Finish, Checkered, BA Finish, No.4 Finish, Etching Finish, Mirror Finish, Sand Blast, 8K Finish, Embossed Finish, etc. |
| Grade | C | Cb+Ta | Cr | Cu | Fe | Mn | Ni | P | S | Si |
| SS 15-5 PH | 0.07 max | 0.15-0.45 max | 14.0-15.0 max | 2.5-4.5 max | Bal | 1.0 | 3.5-5.5 | 0.04 | 0.03 | 1.0 |
| Grade | Tensile Strength ksi (MPa) | Yield Strength 0.2% ksi (min) | Elongation % | Hardness (Rockwell) MAX |
| SS 15-5 PH | 161,000 | 140,000 | 7.6% | C35 |
| STANDARD | UNS | WNR. |
| SS 15-5PH | S15500 | 1.4545 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless steel 15-5 PH sheets and plates offer many benefits, including high strength, hardness, and corrosion resistance, making them ideal for high-performance applications Their high hardness and fatigue resistance enable them withstand extreme conditions such as high pressure and temperature. The ability to heat-treat the alloy into the desired mechanical properties enhances versatility is included. In addition, a pH of 15-5 exhibits excellent weldability and machinability, making it easy to manufacture. It is commonly used in the aerospace, chemical and marine industries due to its strength balance, corrosion resistance and durability in harsh environments
| Surface finish | Thickness (mm) | Width (mm) |
|---|---|---|
| Stainless Steel 15-5 PH 1D – Hot rolled, heat treated, pickled Plate & Sheet | 2.4–12.7 | max. 2032 |
| 2R – Stainless Steel 15-5 PH Cold-rolled, bright-annealed Sheet & Plate | 0.05–1.50 | 3–649 |
| 2H – Stainless Steel 15-5 PH Work hardened Plate & Sheet | 0.05–1.50 | 3–630 |
| 2B – Stainless Steel 15-5 PH Cold rolled, heat treated, pickled, skin passed Sheet & Plate | 0.25–8.0 | max. 2032 |
| 2D – Stainless Steel 15-5 PH Cold rolled, heat treated, pickled Plate & Sheet | 0.4–6.35 | max. 1524 |
| 2E – Stainless Steel 15-5 PH Cold rolled, heat treated, mechanically descaled Sheet & Plate | 0.4–8.0 | max. 2032 |
| 2R – Stainless Steel 15-5 PH Cold rolled, bright annealed Plate & Sheet | 0.25–3.5 | max. 1524 |
| 2H – Stainless Steel 15-5 PH Work hardened Sheet & Plate | 0.4–6.35 | max. 1524 |
| Stainless Steel 15-5 PH Polished, brushed Plate & Sheet | 0.5–4.0 | max. 1524 |
Yes, we offer custom sizes for Stainless Steel 15-5 PH Sheet and Plates to meet specific project needs. Our team at Vipul Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@vipulsheetsplates.com.
| Density | Electrical conductivity (% IACS) | Thermal conductivity (BTU-in/hr-ft²-°F) | Specific heat capacity | Thermal expansion (1/°F) | Melting Point (°F) |
| 0.282 | 1.72 | 97 | 0.11 | 0.00000589 | 2560 |
| Material | Size | Thickness |
|---|---|---|
| PLATES / SHEETS | 1000 mm x 2000 mm | 0.1mm To 100 mm Thickness |
| 1220 mm x 2440 mm (4′ x 8′) | ||
| 1250 mm x 2500 mm | ||
| 1500 mm x 3000 mm | ||
| 2000 mm x 4000 mm | ||
| 2000 mm x 2000 mm |
Stainless Steel 15-5 PH Plates and Sheets find application in aerospace parts, pressure vessels, nuclear reactor components, fasteners, shafts, gears, and structural fittings. Due to their high strength-to-weight ratio and stress corrosion cracking resistance, they are particularly suitable for marine equipment, high-performance mechanical systems, and chemical processing applications. The plates are also appropriate for precision machining, die casting tools, and heavy-duty industrial machinery. SS 15-5 PH has strength, corrosion resistance, and workability, thus being a better material for severe service applications with demanding performance and durability.
