Vipul Sheets and Plates has established itself as a reliable name in the stainless steel sector, providing top-notch SMO 254 Channels to clients throughout Delhi and across India. Renowned for their exceptional product quality, precise engineering, and prompt delivery, Vipul serves a variety of industries that need corrosion-resistant and high-strength materials. SMO 254 is a high-alloy austenitic stainless steel specifically crafted for harsh chloride-rich environments. Vipul’s SMO 254 Channels are well-regarded for their outstanding mechanical strength, resistance to pitting and crevice corrosion, and impressive durability, making them perfect for demanding industrial applications both locally and internationally.
The SMO 254 Channel is mainly made up of iron, featuring key alloying elements like 20% chromium, 18% nickel, 6% molybdenum, and 0.2% nitrogen, which provide remarkable resistance to crevice and pitting corrosion. It also includes trace amounts of manganese, silicon, and copper. In terms of mechanical properties, it boasts a minimum tensile strength of 650 MPa, a yield strength of 300 MPa, and an elongation of 35%. The high levels of molybdenum and nitrogen significantly boost its resistance to chlorides and other aggressive media, making SMO 254 an excellent choice for marine and chemical processing environments.
| Specifications | : | ASTM A 276/A 276M,A 484/A 484M,A 564/A 564M,A 582/A582M,A 638 /A 638M,A705/A705M |
| Dimensions | : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| SMO 254 Angle | : | 5mm to 9mm |
| SMO 254 Channel | : | 40mm*20mm~300mm*300mm |
| SMO 254 Beam | : | 3″ thru 12.31″ |
| SMO 254 Chain | : | 1/8 inch – 1/2 inch Diameter |
| Thickness | : | 3.0mm – 120mm |
| Length | : | 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes |
| Type | : | Angle, C Channel, U Channel, H Beam, I Beam, T Beam, W Beam, Chain |
| Grade | C | Mn | Si | Cu | S | P | Mo | Ni | Cr |
| SMO 254 | 0.02 | 1.0 | 0.08 | 0.5-1.0 | 0.01 | 0.03 | 6.0-6.5 | 17.5-18.5 | 19.5-20.5 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8 g/cm3 | 1320-1390 ℃ | 650 | 300 | 35 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Vipul Sheets and Plates based in Delhi, India, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
SMO 254 Channel offers numerous advantages, including exceptional resistance to pitting, crevice, and stress corrosion cracking, making it ideal for challenging environments like marine and chemical processing. Its high molybdenum content enhances its durability in chloride-rich conditions. The alloy also provides outstanding strength and toughness, even at elevated temperatures. With excellent weldability and formability, SMO 254 is easy to fabricate and maintain. Its superior resistance to general corrosion and high-performance capabilities make it a reliable, long-lasting solution for applications in industries requiring materials to withstand aggressive corrosive environments.
Yes, we offer custom sizes for SMO 254 PH Channel to meet specific project needs. Our team at Vipul Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@vipulsheetsplates.com.
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SMO 254 | 1.4547 | S31254 | 2378 | – | – | Z1 CNDU 20.18.06Az | X1CrNiMoCuN20-18-7 |
SMO 254 Channels are widely utilized in applications that demand superior corrosion resistance and strength in extreme conditions. These applications include desalination plants, chemical and petrochemical processing facilities, marine environments, heat exchangers, and offshore oil and gas platforms. Their capability to endure high pressure, elevated temperatures, and corrosive atmospheres makes them ideal for load-bearing and structural roles in challenging industrial settings. Furthermore, SMO 254 Channels are also employed in power plants, food processing, flue gas cleaning systems, and components exposed to seawater or harsh chemicals, ensuring reliability and a long service life.
