Quenched and Tempered Carbon Steel Sheet and Plate

Vipul Sheets and Plates offers high-strength Quenched and Tempered (Q&T) Carbon Steel Plates and Sheets for critical industrial and structural applications. Q&T plates are subjected to a special heat treatment process that improves their strength, hardness, and toughness. These plates are most suitable for mining machinery, construction machines, pressure vessels, and structural heavy-duty components. Vipul stocks various grades including ASTM A514, EN 10025-6 S690QL, and others. With high-quality checking and accurate processing, Vipul ensures the best mechanical performance, dimensional accuracy, and durable service life in applications of critical load bearing and wear resistance.

Quenched Steel Plates

Tempered Steel Sheet

Tempered HR Plates

High Strength Quenched and Tempered Steel Plate Manufacturer in Delhi, Quenched and Tempered Structural Steel Sheets Delhi, Quenched Steel Plates Supplier in Delhi, Tempered Steel Sheet Exporter in India, Quenched and Tempered Alloy Steel Sheets Price List in Delhi, Quenching and Tempering Steel Sheet Distributor in Delhi, Hot Rolled Steel Tempered Plate Supplier in Delhi, Tempered Steel Sheet Distributor in India, Tempered HR Plates Sizes in mm

Q&T carbon steel usually consists of carbon, manganese, chromium, molybdenum, and boron. On quenching and tempering, tensile strengths become 700–1100 MPa with yield strengths up to 690 MPa based on the grade. Heat treatment makes the plate hard, ductile, and impact resistant. Q&T steels have better wear resistance and fatigue strength. They are structurally sound under high load and cyclic temperatures and thus can be used for dynamic industrial processes. Although they exhibit high strength, they still have enough formability and weldability to be suitable for intricate fabrication work.

Quenched and Tempered Carbon Steel Sheet and Plate Specification

tandard	ASTM A514 and A514M-13
Grade	Grade 400, 80 and 500, WELTEN 140 KSI ,780E, 130 KSI , A514, S890Q, A710, TMCP 100 KSI, RQT 701, S690QL, S690QL1, S890QL1,S690Q, S890QL, Weldox 700, S960QL
Thickness:	3 mm to 300 mm
Width:	3000 mm, 2500 mm, 2000 mm,
Length:	Up to 12000 mm long
Delivery State	Quenched and Tempered

Chemical Composition of Quenched and Tempered Carbon Steel Sheet and Plate

A514 Gr B	A514 Gr A	A514 Gr E	A514 Gr C	A514 Gr Q	A514 Gr H	A514 Gr S	A514 Gr M	A514 Gr F	A514 Gr K	A514 Gr J	A514 Gr R	A514 Gr P	A514 Gr T
C	0.012-0.021	0.015-0.021	0.012-0.020	0.010-0.020	0.014-0.021	0.012-0.021	0.011-0.021	0.012-0.021	0.010-0.020	0.010-0.020	0.012-0.021	0.015-0.020	0.012-0.021	0.008-0.014
M	0.070-1.000	0.080-1.010	0.040-0.070	1.010-1.050	0.095-1.030	0.095-1.030	1.010-1.050	0.045-0.070	0.060-1.000	1.010-1.050	0.045-0.070	0.085-1.015	0.045-0.070	1.020-1.050
P	0.0035	0.0035	0.0035	0.0035	0.0035	0.0035	0.0035	0.0035	0.0035	0.0035	0.0035	0.0035	0.0035	0.0035
S	0.0035	0.0035	0.0035	0.0035	0.0035	0.0035	0.0035	0.0035	0.0035	0.0035	0.0035	0.0035	0.0035	0.0010
Si	0.020-0.035	0.040-0.080	0.020-0.040	0.015-0.030	0.015-0.035	0.020-0.035	0.015-0.045	0.020-0.035	0.015-0.035	0.015	0.020-0.035	0.020-0.035	0.020-0.035	0.040-0.060
Ni	–	–	–	–	1.020-1.050	0.030-0.070	–	1.020-1.050	0.070-1.000	–	–	0.090-1.010	1.020-1.050	–
Cr	0.040-0.065	0.050-0.080	1.040-2.000	–	1.000-1.050	0.040-0.065	–	–	0.040-0.065	–	–	0.035-0.065	0.085-1.020	–
Mo	0.015-0.025	0.018-0.028	0.040-0.060	0.015-0.030	0.045-0.060	0.020-0.030	0.010-0.060	0.045-0.060	0.040-0.060	0.045-0.060	0.050-0.065	0.015-0.025	0.045-0.060	0.045-0.060
V	0.003-0.008	–	–	–	0.003-0.008	0.003-0.008	0.006	–	0.003-0.008	–	–	0.003-0.008	–	0.003-0.008
Ti	0.001-0.003	–	0.001-0.010	–	–	–	–	–	–	–	–	–	–	–
Z		0.005-0.015	–	–	–	–	–	–	–	–	–	–	–	–
Cu	–	–	0.015-0.050	–	–	–	–	–	0.015-0.050	–	–	–	–	–
B	0.0001-0.0005	0.00025	0.0001-0.0005	0.0001-0.0005	–	0.0001-0.0005	0.0001-0.0005	0.0001-0.0005	0.0001-0.0005	0.0001-0.0005	0.0001-0.0005	–	0.0001-0.0005	0.0001-0.0005
Nb	–	–	–	–	–	–	0.006	–	–	–	–	–	–	–

Mechanical Properties of Quenched and Tempered Carbon Steel Sheet and Plate

Grade	A514 Mechanical Property
Grade	Tensile	Yield	Elongation	Thickness
A514	Mpa	Min Mpa	Min %	mm
	760-895	690	18	20
	760-895	690	18	20-65
	690-895	620	18	65-150

Quenched Alloy Steel Plate Price in India, High Strength Tempered Steel Plates Weight Chart, Stockist of Tempered Steel Hot Rolled Plate in India, Quenched and Tempered Steel Plate Supplier in India, HR Quenched Steel Plates Price List in Delhi, Tempered and Quenched Plates Supplier in India, Quenched Low Alloy Steel Sheets Exporter in Delhi, High Yield Structural Quenched Plates Exporter in India, Quenched Sheet in India

If You Are Looking To Buy High Quality Piping Products ?

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

Largest Quenched and Tempered Carbon Steel Sheet and Plate Manufacturer and Exporter in Delhi, India

Vipul Sheets and Plates based in Delhi, India, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.

Quenched & Tempered Carbon Steel Plate Stock list

Standard	Grade	Minimum Thickness (mm)	Maximum Thickness (mm)
Dillinger	Dillimax 890 T	6	100
Dillinger	Dillimax 965 T	6	100
EN10025 – 6	S690QL	6	200
Dillinger	Dillimax 690T	6	200
EN10025 – 6	S690QL1	6	150
Dillinger	Dillimax 690 E	6	150
EN10025 – 6	S890QL	6	100
Dillinger	Dillimax 1100	6	40

Q&T Steel plate Size range

THICKNESS	GRADE	LENGTH	WIDTH
3/16 – 1 1/4 inch	GRADE B	UP TO 480 inch	48″ – 120″
INQUIRE	GRADE P	INQUIRE	INQUIRE
3/16 – 2 1/2 inch	GRADE S	UP TO 480 inch	48″ – 120″
3/16 – 2 inch	GRADE H	UP TO 480 inch	48″ – 120″
3/16– 8 inch	GRADE Q	UP TO 480 inch	48″ – 120″
3/16 – 2 1/2 inch	GRADE F	UP TO 480 inch	48″ – 120″
INQUIRE	GRADE A	INQUIRE	INQUIRE
3/16 – 6 inch	GRADE E	UP TO 480 inch	48″ – 120″

High Strength Tempered Steel Plate Distributor in India, Tempered Steel Plate Supplier in Delhi, Alloy Quenched Plate Weight Chart, HR Quenched Steel Sheet Manufacturer in Delhi, Tempered Alloy Steel Plate Price List in Delhi, Quenching and Tempering Plates Sizes in mm, Tempered Steel Plates Dealer, Quenched and Tempered Steel Hot Rolled Plate India

Quenched and Tempered Carbon Steel Sheet and Plate have several advantages, including superior strength and hardness, making them ideal for high-pressure applications Their high corrosion resistance ensures long-term performance in harsh environments. The tempering process improves hardness and reduces brittleness, resulting in better impact resistance and ductility. These materials also provide excellent machining, making them easier to cut, weld and fabricate. Furthermore, their cost-effectiveness, combined with superior performance makes quenched and tempered carbon steel sheets and plates desirable for industries such as manufacturing, automotive and heavy machinery

Types of Quenched and Tempered Carbon Steel Sheet and Plate

Quenched and Tempered Plate Dealer in Delhi, Quenched Wear Resistant Plate Supplier in Delhi, Quenched and Tempered Alloy Sheet and Plates in Delhi, HR Quenched Steel Sheet Size Chart, Quenching and Tempering Sheet in India, Quenched and Tempered Steel Hot Rolled Plate Stockist, High Yield Structural Tempered and Quenched Plates Manufacturer in India, Tempering Sheets and Plates Stockist in Delhi, Tempered Low Alloy Steel Plate Supplier in India

Are Custom Sizes Available for Quenched and Tempered Carbon Steel Sheet and Plate?

Yes, we offer custom sizes for Quenched and Tempered Carbon Steel Sheet and Plate to meet specific project needs. Our team at Vipul Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@vipulsheetsplates.com.

Customer Support

Largest Inventory

On Time Delivery

Quality Assurance

Competitive Pricing

Application Industry of Quenched and Tempered Carbon Steel Sheet and Plate

Q&T Carbon Steel Sheets and Plates find applications in mining and earthmoving equipment, cranes, truck chassis, bridges, offshore platforms, and defense armor. Due to their high strength and impact toughness, they are ideal for blast-resistant and load-bearing parts. In the energy industry, they are utilized in wind turbine towers, pressure parts, and subsea structures. These plates are also employed in farm equipment, building beams, and motor vehicle crash protection systems. Their high strength and hardness in extreme working conditions make them irreplaceable in structural efficiency and safety industries.
