Vipul Sheets and Plates, an Indian Delhi-based company, is a trusted Nickel Alloy 201 Angles manufacturer and supplier providing precision-engineered nickel products designed to be utilized in extremely corrosive and high-temperature conditions. Fabricated according to international standards, Vipul’s Nickel 201 Angles are extensively used in chemical processing, marine, electronics, and aerospace industries. With outstanding machinability, purity, and consistent performance, these angles are supplied with quality assurance and prompt service to customers in India and overseas markets.
Nickel Alloy 201 is a commercially pure wrought nickel alloy containing at least 99.6% nickel with low carbon content (≤0.02%), making it highly resistant to graphitization and intergranular embrittlement when exposed to higher temperatures. It possesses good thermal and electrical conductivity, as well as superior corrosion resistance in neutral and reducing media. The alloy provides fair mechanical properties over a broad temperature range and is readily formable and weldable.
ducing media. The alloy provides fair mechanical properties over a broad temperature range and is readily formable and weldable.
Specifications : ASTM B160 / ASME SB160
Angle Size Range : 20 x 20 mm to 100 x 100 mm
Angles Thickness : 3 to 12 mm (depending on size)
Length : 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Nickel 201 | 0.02 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Nickel 201 | 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Nickel 201 | 2.4068 | N02201 | NW 2201 | NA 12 | НП-2 | – | LC-Ni 99 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Nickel Alloy 201 Angles offer exceptional corrosion resistance, making them ideal for chemical processing and marine environments. They exhibit excellent thermal and electrical conductivity, ensuring efficiency in heat exchangers and electrical components. Their high strength and toughness provide durability in harsh conditions. Nickel Alloy 201 is highly oxid-resistant, making it suitable for high-temperature applications. Its ease of fabrication and weldability enhance versatility across industries. The alloy’s magnetic and chemical stability also ensures reliable performance in sensitive applications like electronics and food processing, emphasizing cost-effectiveness and long-term durability.
Nickel Alloy 201 Angles find applications in chemical processing equipment, caustic handling systems, marine hardware, the manufacture of synthetic fibers, power generation, and electrical and electronic uses. They are particularly suitable for alkali and acid environments such as those involving caustic soda, food-grade chemicals, and salt solutions. Their strength of structure and resistance to corrosive attack render them suitable for brackets, frames, supports, trays, and other fabricated components in aggressive industrial exposures. Nickel 201 Angles provide a trustworthy and durable solution where chemical purity, conductivity, and corrosion resistance to harsh environments are essential.
