Vipul Sheets and Plates, located in Delhi, India, stands out as a leading manufacturer and supplier of Duplex Steel Sheets and Plates S32205. They provide top-notch materials designed to meet the rigorous demands of industrial settings. These duplex stainless steel sheets and plates are highly regarded for their remarkable strength, resistance to corrosion, and long-lasting durability. Crafted from high-quality raw materials, they excel in resisting pitting, stress corrosion cracking, and crevice corrosion. Vipul Sheets and Plates is committed to precision engineering, following international standards, and ensuring timely delivery, making them a reliable partner for clients in various sectors, including petrochemicals, marine, construction, and offshore industries.
The Duplex Steel Sheets and Plates S32205 feature a well-balanced microstructure, consisting of about 22% chromium, 5–6% nickel, 3% molybdenum, along with a blend of nitrogen and manganese. This dual-phase structure significantly boosts both strength and corrosion resistance. These sheets boast impressive mechanical properties, including a high tensile strength of around 620 MPa, a yield strength of 450 MPa, and excellent elongation of up to 25%. Their toughness and durability at extreme temperatures make them perfect for structural applications in harsh and corrosive environments.
| Specification | ASTM A 815, ASME SA 815, ASTM A 182, ASME SA 182 |
| Type | Seamless / Welded / Fabricated |
| Range | ½”NB to 24″NB in Sch 10S, 40S, 80S, 160s, XXS |
| Dimensions | ANSI/ASME B16.9, B16.28, MSS-SP-43 |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| S32205 | 0.030 max | 2.00 max | 1.00 max | 0.030 max | 0.020 max | 21.0 – 23.0 | 2.50 – 3.50 | 4.50 – 6.50 | 0.8 – 0.20 | 63.54 min |
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| S32205 | 7.8 g/cm3 | 1350 °C (2460 °F) | Psi – 116000 , MPa – 800 | Psi – 80000 , MPa – 550 | 15 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Duplex Steel Sheet and Plates S32205 offer a combination of high strength and excellent corrosion resistance, making them ideal for harsh environments. Their balanced microstructure of austenite and ferrite enhances resistance to stress corrosion cracking, pitting, and crevice corrosion. With superior mechanical properties, including high tensile strength and yield strength, S32205 is highly durable and reliable. These plates also offer excellent weldability and formability, making them versatile for various industrial applications such as chemical processing, offshore, and marine industries. They provide a cost-effective alternative to more expensive high-alloy steels in demanding conditions.
Yes, we offer custom sizes for Duplex Steel Sheet and Plates S32205 to meet specific project needs. Our team at Vipul Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@vipulsheetsplates.com.
| Duplex 2205 | UNS S31803 | 1.4462 | F51 |
| Thickness (mm) | Length x width (mm) | Length x width (mm) | Length x width (mm) | Length x width (mm) | Length x width (mm) |
| 5 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 6 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 8 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 10 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 12 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 15 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 16 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 20 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 25 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 30 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 35 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 40 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 45 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 50 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 60 | 4000 x 2000 | ||||
| 70 | 4000 x 2000 | ||||
| 80 | 4000 x 2000 | ||||
| 90 | 4000 x 2000 | ||||
| 100 | 4000 x 2000 |
| Surface finish | Thickness (mm) | Width (mm) |
|---|---|---|
| 2B – Cold rolled, heat treated, pickled, skin passed | 0.25–8.0 | max. 2032 |
| 2D – Cold rolled, heat treated, pickled | 0.4–6.35 | max. 1524 |
| 2E – Cold rolled, heat treated, mechanically descaled | 0.4–8.0 | max. 2032 |
| 2R – Cold rolled, bright annealed | 0.25–3.5 | max. 1524 |
| 2H – Work hardened | 0.4–6.35 | max. 1524 |
| Polished, brushed | 0.5–4.0 | max. 1524 |
Duplex Steel Sheets and Plates S32205 find extensive use in industries that require high mechanical strength and exceptional corrosion resistance, such as chemical processing, oil and gas, marine engineering, desalination plants, and the pulp and paper sector. These plates are particularly suited for pressure vessels, storage tanks, heat exchangers, pipelines, and structural components in offshore platforms. Their ability to endure harsh chemicals and saline conditions, combined with outstanding weldability and fatigue strength, makes them the go-to choice for demanding applications that require reliable performance and minimal maintenance.
