Vipul Sheets and Plates, located in Delhi, India, is a reliable manufacturer and supplier of **Carbon Steel EN9 Sheets and Plates** known for providing high-strength, wear-resistant products with application in a variety of **engineering, automotive, and industrial** sectors. These plates and sheets find extensive application in the production of **shafts, gears, keys, spindles, crankshafts**, and **machine tools**. Vipul provides optimum dimensional accuracy, uniform surface finish, and conformation to global quality standards.
**Carbon Steel EN9** equivalent to **AISI 1055** is a **medium carbon steel** having around **0.50–0.60% carbon**, which is characterized by having a very good **tensile strength, machinability**, and the ability to be **hardened and tempered**. It has a very fine toughness-wear resisting balance.
Grade : EN9 Low Alloy Steel Plate
Thickness : from 3mm up to as thick as 150mm
Length :3000mm-18000mm
Supply Condition : As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement.
Impact tested : -52° C
Process of Manufacturing : Hot-Rolled (HR)
Element | C | Si | Mn | P | S | Cr |
Content(%) | 0.50-0.60 | 0.4 Max | 0.50-0.80 | 0.035 Max | 0.015-0.035 | 0.30 Max |
Condition |
N |
R |
S |
T |
Ruling Section,mm |
254 |
100 |
65 |
20 |
Tensile Strength,Mpa |
600-700 |
690-850 |
770-930 |
850-1000 |
Yield Strength,Mpa |
≥310 |
≥415 |
≥480 |
≥570 |
Elongation |
13% |
14% |
14% |
12% |
Hardness, HBW |
201-255 |
201-255 |
223-277 |
248-302 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Carbon Steel EN9 Sheets and Plates offer numerous advantages, including high tensile strength and durability, making them ideal for heavy-duty applications. Their excellent wear resistance ensures long-lasting performance, even in harsh conditions. EN9 steel also provides superior toughness, reducing the risk of fractures under stress. With good machinability and weldability, these plates are easy to fabricate and customize for various applications. Additionally, EN9 steel is cost-effective while maintaining exceptional strength and performance, making it a popular choice in engineering, automotive, and industrial sectors for high-performance components and structural parts.
Yes, we offer custom sizes for Carbon Steel EN9 Sheet and Plates to meet specific project needs. Our team at Vipul Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@vipulsheetsplates.com.
