A reputable producer and supplier of Carbon Steel EN24 Sheets and Plates, Vipul Sheets and Plates is based in Delhi, India, and is well-known for its exceptional toughness, wear resistance, and mechanical strength. A premium alloy steel that is perfect for engineering components subjected to high stress and dynamic loads is EN24, also known as 817M40. Vipul Sheets and Plates provides precision-engineered products that are widely used in industries like industrial machinery, power generation, automotive, and aerospace and that satisfy international quality standards. The business guarantees dependable and high-performance steel solutions with a dedication to quality, competitive pricing, and prompt delivery.
Carbon (0.36–0.44%), nickel (1.3–1.7%), chromium (0.9–1.4%), molybdenum (0.2–0.4%), and iron make up the base of carbon steel EN24 sheets and plates. These alloying elements improve fatigue resistance, strength, and hardness. High tensile strength (850–1000 MPa), yield strength (~680 MPa), and good elongation (13–15%) are all displayed by EN24 steel. It can be heat-treated to produce a variety of mechanical properties and has outstanding toughness and wear resistance. The material is perfect for parts that need precise machining and structural stability because it functions consistently under high mechanical stress.
| Thickness | from 3mm up to as thick as 150mm |
|---|---|
| Size | from 2000 x 1000mm up to 4000 x 2000mm |
| Length | 3000mm-18000mm |
| Supply Condition | As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement. |
| Impact tested | -52° C |
| Process of Manufacturing | Hot-Rolled (HR) |
| Grade | Mn | Si | C | Cr | P | Ni | S | Mo |
| EN – 24 | .50 – .80 | .10 – .35 | .35 – .45 | .90 – 1.40 | 0.04 | – | 0.04 | .20 – .40 |
| Condition | Tensile Strength Rm N/mm² | Yield Stress Re N/mm² | Elongation% | Impact KCV J | Hardness Brinell HB |
| T | 850-1000 | 650 | 13 | 35 | 248-302 |
| U | 925-1000 | 755 | 12 | 42 | 269-331 |
| V | 1000-1150 | 850 | 12 | 42 | 293-352 |
| W | 1075-1225 | 940 | 11 | 35 | 311-375 |
| X | 1150-1300 | 1020 | 10 | 28 | 341-401 |
| Y | 1225-1375 | 1095 | 10 | 21 | 363-429 |
| Z | 1550 | 1235 | 5 | 9 | 444 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Carbon Steel EN24 Sheets and Plates offer several advantages, including excellent tensile strength and durability, making them ideal for high-stress applications. Their resistance to wear and fatigue ensures long-term performance in demanding environments. EN24 steel provides high toughness and impact resistance, reducing the risk of cracking or failure under load. It also offers good machinability and weldability, allowing for easy fabrication into custom parts. Widely used in automotive, aerospace, and engineering sectors, EN24’s reliability and strength make it a preferred choice for heavy-duty components and structural applications.
Yes, we offer custom sizes for Carbon Steel EN24 Sheet and Plates to meet specific project needs. Our team at Vipul Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@vipulsheetsplates.com.
Industries that require materials with high strength and resistance to fatigue make extensive use of carbon steel EN24 sheets and plates. They are perfect for producing aerospace parts like landing gear and actuator systems, as well as automotive parts like axles, crankshafts, and gear shafts. EN24 is utilised in heavy engineering for bolts, couplings, shafts, and machine tool spindles. It is also appropriate for high-load mechanical structures, hydraulic systems, and construction. For crucial applications where performance, durability, and dimensional accuracy are crucial, EN24 is the material of choice because of its high tensile strength and resistance to wear.
