Vipul Sheets and Plates is a leading supplier and manufacturer of premium-quality Aluminium 2024 Plates and Sheets in Delhi, India. The company is known to provide products that adhere to global standards and serves industries that require precision and strength. Aluminium 2024 is a high-strength alloy used mainly in aerospace and structural purposes. Vipul maintains strict quality control and sophisticated processing methods to fulfill customer requirements. Through a well-established distribution system and trained manpower, Vipul offers prompt delivery and technical services, thus being a dependable supplier of Aluminium 2024 plates and sheets to domestic as well as international customers.
Aluminium 2024 is primarily composed of aluminium (90.7–94.7%) with copper (3.8–4.9%) as the main alloying element and trace amounts of magnesium and manganese. This alloy has high strength-to-weight ratio and fatigue strength. Mechanical properties of the alloy are high tensile strength of approximately 470 MPa and yield strength of approximately 325 MPa in T3 condition. Although it is not highly corrosion resistant, Aluminium 2024 can be heat-treated and provides greater structural strength. Its strong mechanical characteristics make it a favorite material for applications under high stress and loads.
| Standards | ASTM B209 / ASME SB209 |
| Temper | O,H12,H14,H16,H18,H19,H22,H24 |
| Thickness | 0.2-50 |
| Width | 100-2600 |
| Length | 500-10000 |
| Surface | Bright, polished, hair line, brush, sand blast, embossed, etching, etc. |
| Finish | Mill, Customer specific finish |
| Aluminum Sheet/ Plate Coating | PVC Coated, Color Coated, Polyester, Fluorocarbon, polyurethane and epoxy coating |
| Type | Hot-Rolled (HR) / Cold-Rolled (CR) Sheet |
| Grade | Al | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Other |
| min. | Bal | 3.80 | 0.30 | 1.20 | ||||||
| max. | Bal | 0.50 | 0.50 | 4.90 | 0.90 | 1.80 | 0.10 | 0.25 | 0.15 | 0.05 |
| Temper | Tensile Strength | Yield Strength | Elongation |
| KSI | KSI | % | |
| (annealed) | 32 | 14 | 12 |
| T3 | 63 | 42 | 15 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Aluminium 2024 Sheets and Plates offer several advantages, including exceptional strength and high fatigue resistance, making them ideal for aerospace, military, and structural applications. The high copper content enhances its mechanical properties, providing superior strength-to-weight ratio, which is essential in weight-sensitive industries like aviation. Aluminium 2024 also offers good machinability, allowing for complex designs and precise fabrication. While it has moderate corrosion resistance, it can be treated with coatings for enhanced durability. Its high performance, combined with excellent wear resistance, makes it a preferred choice for demanding environments.
| European Standard | OLD | WNr | UNS | ISO | USA (AA) | GERMANY (DIN) |
| AW-AlCu4Mg1 | AU4G1 | 3.1355 | A92024 | AlCu4Mg1 | 2024 | AlCuMg2 |
| Sizes (mm) | Theoretical Mass KG/Plate |
|---|---|
| 2000 X 1000 X 0.5 | 2500 X 1250 X 0.5 |
| 2000 X 1000 X 0.7 | 2500 X 1250 X 0.7 |
| 2000 X 1000 X 0.9 | 2500 X 1250 X 0.9 |
| 2000 X 1000 X 1.2 | 2500 X 1250 X 1.2 |
| 3000 X 1500 X 1.2 | 2000 X 1000 X 1.6 |
| 2500 X 1250 X 1.6 | 3000 X 1500 X 1.6 |
| 2000 X 1000 X 2.0 | 2500 X 1250 X 2.0 |
| 3000 X 1500 X 2.0 | 2500 X 1250 X 2.5 |
| 2.79 | 4.36 |
| 3.91 | 6.10 |
| 5.02 | 7.85 |
| 6.74 | 10.46 |
| 15.01 | 8.93 |
| 13.95 | 20.09 |
| 11.16 | 17.44 |
| 25.11 | 21.80 |
Aluminium 2024 Sheets and Plates are heavily utilized in aircraft applications, such as fuselage structures of an aircraft, wings, and skins, owing to their high strength and fatigue life. Automotive also uses this alloy in such critical applications as suspension systems and structural panels. It also has applications in military and defense machinery, marine structural components, and precision equipment. It is highly machinable, which permits easy fabrication to intricate parts, so it is perfectly suited for tooling, molds, and machine components. While not appropriate for corrosive environments without protection, it performs well in dry, high-stress conditions needing light but strong material.
